住宅房屋施工详图设计

Shop drawings are detailed construction drawings used to guide the accurate execution of a house. They include precise details for various building components such as the structure, walls, doors, windows, roofs, electrical and mechanical systems, as well as finishing details and materials.

These drawings serve as a key reference for contractors and workers to ensure that the architectural and structural designs are implemented according to the technical specifications and quality standards. They show exact dimensions, materials, and the arrangement of elements on site.
